Armour belt location--K Class Light Cruiser (german)

Discussion in 'Washington Cascade Column' started by joe thomer, Apr 18, 2011.

  1. joe thomer

    joe thomer Active Member

    Joined:
    Sep 25, 2010
    Posts:
    194
    The konigsberg Light cruiser is showing a armour belt in its specs. not sure how to locate the 1/16 armour belt on the hull. established the water line, came down the 3/8 from the top of the hull for the sub deck. Is the armour belt (1/6 thick) located 50 percent between the water line and the bottom of the 3/8 mark for the sub deck?

    joe thomer, Apr 18, 2011
    #1
  2. Peter Thomer

    Peter Thomer New Member

    Joined:
    Apr 15, 2011
    Posts:
    5
    :):(:p:mad::confused:o_O:doze::laugh::rolleyes::blink::crying::sick::kiss::woot::whistling::eek::D;):blush::cool::cry::laugh::plain::ermm::mad::pinch::p:cool::confused:is this working

    Peter Thomer, Apr 18, 2011
    #2
  3. joe thomer

    joe thomer Active Member

    Joined:
    Sep 25, 2010
    Posts:
    194
    yes pete...it came thru

    joe thomer, Apr 18, 2011
    #3
  4. NickMyers

    NickMyers Admin RCWC Staff

    Joined:
    Nov 15, 2007
    Posts:
    4,405
    Location:
    Federal Way, WA
    the belt belongs wherever the plans show it.
    [​IMG]
    You can just make it out above the waterline in this picture

    NickMyers, Apr 18, 2011
    #4
  5. Peter Thomer

    Peter Thomer New Member

    Joined:
    Apr 15, 2011
    Posts:
    5
    with looking at the picture and then at the plans it make sense. the armour belt is a rectangle that is half above the water line and half below. so the for and aft position are easily marked, but the vertical looks to be located in side the rectangle, anyware inside.

    Peter Thomer, Apr 18, 2011
    #5
