Diaphragm Pumps?

Discussion in 'Research and Development' started by modelshipsahoy, Nov 23, 2018.

  1. modelshipsahoy

    modelshipsahoy Vendor

    Joined:
    Jul 19, 2018
    Posts:
    584
    Location:
    Michigan
    Are Diaphragm Pumps not allowed by rules? Everything seems to address impelled pumps.

  2. SnipeHunter

    SnipeHunter Well-Known Member

    Joined:
    Aug 22, 2007
    Posts:
    1,331
    Correct, all positive displacement pumps are illegal. It's the first rule in the pump section.

  3. Kotori87

    Kotori87 Well-Known Member

    Joined:
    Nov 8, 2006
    Posts:
    3,139
    Positive-displacement pumps are prohibited because they are (theoretically) capable of putting the same quantity of water through any diameter outlet, thus negating the purpose of the standard 1-unit and 1/2-unit pump restrictors used in Fast Gun ships. Unfortunately this removes them from service as ballast pumps aboard submarines, a purpose for which they are ideally suited.

  4. modelshipsahoy

    modelshipsahoy Vendor

    Joined:
    Jul 19, 2018
    Posts:
    584
    Location:
    Michigan
    What about air pumps?

  5. Kotori87

    Kotori87 Well-Known Member

    Joined:
    Nov 8, 2006
    Posts:
    3,139
    Alas, the current phrasing of the rules for submarines specifies that submarine pumps must pump water into and out of a ballast tank. No air, no positive-displacement, etc. This prohibits both air compressors (because they're positive displacement), and air pumps (because they pump air, not water). The Fast Gun rules regarding submarines are very poorly written, making any such project significantly more difficult than it needs to be. I would be more annoyed by that but I have too many surface ship projects to try rewriting the rules.

  6. modelshipsahoy

    modelshipsahoy Vendor

    Joined:
    Jul 19, 2018
    Posts:
    584
    Location:
    Michigan
    That can’t be exactly true because the I-400 I saw (Franks?) used co2 to blow the tanks.

    I thought about bellow tanks, but it can be argued that they are essentially diaphragm pumps anyway, so why crowd out the cabin with extra complexity and moving parts.

    My concept is basically a snorkeling sub with a little diaphragm air pump to blow the tanks using surface air drawn through a snorkel. Then a bleeding valve to dive.

    At this point I’m Damn the Torpedoes! Full speed ahead. If I show up a NATS and they want to toss out the coolest ship there even if it meets the intent of the rules, then so be it. I’ll call ‘em a bunch of Fraidy Cats scared of a little 1.5 unit novelty store clearance rack special.

    .... hopefully NATS will be at Saranac so I won’t have so far of a drive of shame home. Lol

    Last edited: Nov 24, 2018
  7. Kevin P.

    Kevin P. Well-Known Member

    Joined:
    Mar 29, 2015
    Posts:
    1,540
    Location:
    Alexandria, VA
    Type type type type type. A wise voice once said, ‘build it and they will come.’ The number of keystrokes for a post typically exceeds the number of key strokes for a rule proposal. Most would recommend building a capital ship that doesn’t shoot its load in a few seconds, putting a sub in the MI lake would have a similar recovery rate as the mars rover

  8. modelshipsahoy

    modelshipsahoy Vendor

    Joined:
    Jul 19, 2018
    Posts:
    584
    Location:
    Michigan
    Shoeless Joe Jackson said that. Not sure how wise he was considering the tactical advantage of shoes.....

    No worries Kevin. The modelshipsahoy surface fleet will be there in force.

    NickMyers likes this.
  9. NickMyers

    NickMyers Admin RCWC Staff

    Joined:
    Nov 15, 2007
    Posts:
    4,393
    Location:
    Federal Way, WA
    :laugh::laugh::laugh:
    [​IMG]

  10. modelshipsahoy

    modelshipsahoy Vendor

    Joined:
    Jul 19, 2018
    Posts:
    584
    Location:
    Michigan
    Guessing it would be a high priority target?
    Lol. That says a lot.

    Last edited: Nov 24, 2018
  11. modelshipsahoy

    modelshipsahoy Vendor

    Joined:
    Jul 19, 2018
    Posts:
    584
    Location:
    Michigan
    Not your standard “Typist” attire.

    Kevin P. likes this.
  12. Anvil_x

    Anvil_x Well-Known Member

    Joined:
    Nov 4, 2017
    Posts:
    1,415
    Location:
    Park Falls, WI
    Saranac's pretty deep. it's super clear, but it gets deep really fast. I think that's their point. The alternate site would be pretty decent though. but if you brought a sub to Saranac, you'd really have to be careful not to accidentally hit crush depth or something.

    I dunno, I think swimming at Saranac would be pretty pleasant in mid july. But I'm weird, I guess? am I the only guy that brings swim trunks or something? Definitely don't want to sink there in september or october though. Kas and the gang let me get the boat back to the dock before Will swung in for the coup de grace during the October scrap.

    that would have been a long cold drive back to Wisconsin if it had gone down where the Baden and Derf had it clobbered.
    But next year.... Oh next year..... we shall see.

    Panzer, Beaver and modelshipsahoy like this.
  13. Kevin P.

    Kevin P. Well-Known Member

    Joined:
    Mar 29, 2015
    Posts:
    1,540
    Location:
    Alexandria, VA
    Need to consider the muck factor, during nats randy’s boat lawn-darted (as we’d say in the real sub driving world) and had about half of the 50” length visible above, lodged vertically. The MI pond (and others) has a few feet of muck. The MI pond specifically gets over head depth within about 3-4 steps from shore, which is way deeper than the typical nats ponds. I spent 20ish minutes looking for a prop in the muck a few feet (and neck depth) from shore. I found it miraculously by moving my hands through the gunk on the bottom, I also was sick for a week following (not sure if causation or just correlation)

  14. modelshipsahoy

    modelshipsahoy Vendor

    Joined:
    Jul 19, 2018
    Posts:
    584
    Location:
    Michigan
    Hoping to set the neutral buoyancy of the sunk model at about 4 feet. Operational dive depth will only be 12” lest it drowns it’s snorkle.

  15. Kevin P.

    Kevin P. Well-Known Member

    Joined:
    Mar 29, 2015
    Posts:
    1,540
    Location:
    Alexandria, VA
    I’d love to see your fluid dissolved solid and temperature mapping capabilities

  16. modelshipsahoy

    modelshipsahoy Vendor

    Joined:
    Jul 19, 2018
    Posts:
    584
    Location:
    Michigan
    Lol. ABOUT. We’re talking a 31” model. Variables are negligible.

    I’m pretty sure I can keep it from spiraling down 20 feet to the abyss.

  17. modelshipsahoy

    modelshipsahoy Vendor

    Joined:
    Jul 19, 2018
    Posts:
    584
    Location:
    Michigan
    Also considered a seaplane float on a self retracting bobbin. Would stay on the surface as the model dives, retract back upon surfacing and keep paying out on a sink. Thoughts?

  18. Kevin P.

    Kevin P. Well-Known Member

    Joined:
    Mar 29, 2015
    Posts:
    1,540
    Location:
    Alexandria, VA
    Out of everything you’ve said, having a prop fouling device would probably be the only thing that people would raise concern about (and would not be allowed)

  19. modelshipsahoy

    modelshipsahoy Vendor

    Joined:
    Jul 19, 2018
    Posts:
    584
    Location:
    Michigan
    Good to know. Maybe release by a pressure trigger set for 2 psi (4.5 ft typically in freshwater)

  20. buttsakauf

    buttsakauf Admiral (Supporter)

    Joined:
    Oct 14, 2010
    Posts:
    694
    Location:
    San Diego, CA
    I respectfully disagree;-) Mud-dart was the term of choice with us Torpedoman’s Mates at one point many moons ago.

    Edit: In addition to... avoid becoming a 8000t mud dart there is also no water in the people tank and a 1 to 1 ratio of dives to surfaces to be maintained.
