Discussion in 'Warship Builds' started by McSpuds, Jun 9, 2015.

  1. McSpuds

    McSpuds Vendor

    Joined:
    Aug 22, 2011
    Posts:
    780
    Location:
    Louisville, Ky
    Welcome to the latest build in SpudsWerk's Shop, the Evstafi Class Predread, loan Zlatoust, "The Saint".

    She has a 74 foot beam so is allowed one sidemount. 28 sec, 2 shaft, 1 rudder. Very short, fat Predread.

    I watched this last month as Tugboat's Evstafi jumped around the pond and was very impressed with the ship.

    If I get her on the water soon, she will fight as axis along side my VDT, and afterwards will go allied. She was captured by the Germans early in 1918 and handed back over after the end of the war. So she may fight either side.

    So here we go.... Za Rodina


    Frames being laid out

    [​IMG]

    Time to skin the bottom in prep for glassing. I used balsa between the ribs to form the water channel before skinning
    [​IMG]

    I stained the deck area before glassing bottom in case I got some on the wood. It is hard to stain wood after resin is in it.
    [​IMG]

    The nice slanted bow area for the anchor... even has the pen area done..
    [​IMG]

    Decking fitting with raised super
    [​IMG]

    Casements where fun on this one...
    [​IMG]


    Here you can see the channeling. The pump area has not been cut out yet. I like to cut this out after the glassing of the bottom.
    [​IMG]

    [​IMG]


    The hollow super
    [​IMG]

    The VDT in the background getting ready to skin for NATS
    [​IMG]

    Some internal brackets for pump and motors
    [​IMG]

    The bottle area
    [​IMG]


    Pump mount
    [​IMG]

    Still using a carl pump with Charlies Auto switch... keeps on ticking!
    [​IMG]

    Universals for the brushless 3mm to 1/8
    [​IMG]

    motor mounts
    [​IMG]

    Battery is under the bottle
    [​IMG]

    Almost ready for wiring...
    [​IMG]

    Last edited: Jun 9, 2015
  2. Bob

    Bob Well-Known Member

    Joined:
    Jun 14, 2007
    Posts:
    1,058
    I started with bow guns in my Zyrini. That had a slight down angle and hit 1.5' in front of the ship. They worked great for shooting targets. Not very good for shooting ships, even a tall convoy ship. The main problem was the small size of the ship. If the water is anything but flat calm the ship pitches all over the place. A couple of big ships driving near you and making a waves was a killer. The bow guns never really point at the same place when firing. I had lots of bbs fired, not a lot of hits. I had made the guns and the ship able to flip from a stern sidemount and bow guns to twin sterns and a bow sidemount. After one year I changed and it has worked much better.
    If you keep the current down angle you might have more luck.
    I put 3-5amp 6 volt packs in it, what size battery are you using?

  3. McSpuds

    McSpuds Vendor

    Joined:
    Aug 22, 2011
    Posts:
    780
    Location:
    Louisville, Ky
    8ah 7.4 lipo

  4. Bob

    Bob Well-Known Member

    Joined:
    Jun 14, 2007
    Posts:
    1,058
    I started with a Stinger pump in mine but it used too much power so I changed to a 380 cruiser motor on a BB sized pump. Went from 20 amps to 10 amps.
    What do the brushless pump and drive motors need for amps?

  5. thegeek

    thegeek Well-Known Member

    Joined:
    Apr 20, 2008
    Posts:
    798
    Location:
    Mongo
    more

  6. Tugboat

    Tugboat Facilitator RCWC Staff Admiral (Supporter)

    Joined:
    Jan 10, 2007
    Posts:
    8,309
    Location:
    Statesboro, GA
    She does pretty well with the dual bows. They hit the water about 6-8 inches from the now, and you can watch them travel underwater a good bit. I'm still getting the hang of running Evstafi but got 6 kills at the last battle. 2 Badens, 2 I-boats, a cruiser and something else. Got a few shots in on Caleb's Kongo, too ,but he was too fast to mess with :)

  7. McSpuds

    McSpuds Vendor

    Joined:
    Aug 22, 2011
    Posts:
    780
    Location:
    Louisville, Ky
    The one battery will last for about 5 or 6 sorties.

    I have 4 of them and they charge in about 45 min.

  8. McSpuds

    McSpuds Vendor

    Joined:
    Aug 22, 2011
    Posts:
    780
    Location:
    Louisville, Ky
    The turrets on the Evstafi class are taller than any I have seen in the hobby....... Down angle is not a issue with the bow guns at all.

  9. Lou

    Lou It's just toy boats -->> C T D <<-- Admiral (Supporter)

    Joined:
    Jan 31, 2008
    Posts:
    1,771
    Location:
    Smyrna, Georgia
    Check out the American pre-dreds if you want a tall turret, one is mounted on top of the other.
    [​IMG]

  10. absolutek

    absolutek -->> C T D <<--

    Joined:
    Sep 6, 2009
    Posts:
    1,708
    Location:
    Ontario, Canada
    You'd still have to mount it in the lower turret where the main armament was though.

    Tugboat likes this.
  11. Lou

    Lou It's just toy boats -->> C T D <<-- Admiral (Supporter)

    Joined:
    Jan 31, 2008
    Posts:
    1,771
    Location:
    Smyrna, Georgia
    Yes, but the top part of the gun could go into the top turret, just have the barrel exit the lower turret. Then again, that is a turkey of a ship

  12. Tugboat

    Tugboat Facilitator RCWC Staff Admiral (Supporter)

    Joined:
    Jan 10, 2007
    Posts:
    8,309
    Location:
    Statesboro, GA
    Not really, it's a little longer than Evstafi, same prop and rudder...

  13. McSpuds

    McSpuds Vendor

    Joined:
    Aug 22, 2011
    Posts:
    780
    Location:
    Louisville, Ky
    Nope, it is clear that secondary is a additional turret on top of the main. All guns have to be in the main turret...

  14. McSpuds

    McSpuds Vendor

    Joined:
    Aug 22, 2011
    Posts:
    780
    Location:
    Louisville, Ky
    That is a kewl looking ship though, and the main turret is rather tall... look at the sailors close by for est height.... lots of casements at waterline too... nice

  15. McSpuds

    McSpuds Vendor

    Joined:
    Aug 22, 2011
    Posts:
    780
    Location:
    Louisville, Ky
    yepper

    absolutek likes this.
  16. Tugboat

    Tugboat Facilitator RCWC Staff Admiral (Supporter)

    Joined:
    Jan 10, 2007
    Posts:
    8,309
    Location:
    Statesboro, GA
    Actually, the upper deck of the turret is not separate, it is one big turret with 4 guns in it. BUT. The rules do say that cannons must be mounted in the turrets of the main armament (or in casements occupied by main armament), and then they say: '9.a. Cannons mounted in turrets shall extend from the face of the turret in the same manner as the actual ship being modeled.' Which means they'd have to go where the big guns go. Lou is correct, and smarter than I am*, and correctly points out that the bigger turret gives lots of room for the non-barrel parts of the cannon. Good idea!

    *Because he thought of it first. (Maybe also for other reasons, but that's the specific reason there).

    Lou likes this.
  17. Lou

    Lou It's just toy boats -->> C T D <<-- Admiral (Supporter)

    Joined:
    Jan 31, 2008
    Posts:
    1,771
    Location:
    Smyrna, Georgia
    LOL. I usually have issues with down angle and the top of the elbow, this unusual arrangement where it truly is one turret bolted to the other would give you plenty of room for the elbow. The gun barrel would still exit the main turret face.

  18. McSpuds

    McSpuds Vendor

    Joined:
    Aug 22, 2011
    Posts:
    780
    Location:
    Louisville, Ky
    Too bad the ship was launched in 1904. Missed our cutoff by just a couple of months...

  19. McSpuds

    McSpuds Vendor

    Joined:
    Aug 22, 2011
    Posts:
    780
    Location:
    Louisville, Ky
  20. absolutek

    absolutek -->> C T D <<--

    Joined:
    Sep 6, 2009
    Posts:
    1,708
    Location:
    Ontario, Canada
    And yet it is still on the ship list, and therefore approved according to the rules.
