    I've recently been designing a ship's hull. I thought it might be fun to post a photo of the model and see if anybody can guess what ship it is.
    (Nick, you can't guess since you already know ;))
    Have fun! :)
    Guess Hull.png

    Beaver, Mar 20, 2017
    #1
  2. SteveT44

    SteveT44 Well-Known Member

    Joined:
    Nov 1, 2009
    Posts:
    1,856
    Location:
    MD
    A Panamax car carrier? ;)

    [​IMG]

    SteveT44, Mar 20, 2017
    #2
    NickMyers likes this.
  3. Beaver

    Beaver 2020 Rookie of the Year Admiral (Supporter)

    Joined:
    Apr 12, 2013
    Posts:
    3,676
    Location:
    Central PA
    Ohh yeah, did I say that the model wasn't finished yet? Sorry I got your hopes up there, Steve. ;)

    Last edited: Mar 20, 2017
    Beaver, Mar 20, 2017
    #3
  4. SteveT44

    SteveT44 Well-Known Member

    Joined:
    Nov 1, 2009
    Posts:
    1,856
    Location:
    MD
    I just look at the lines......

    SteveT44, Mar 20, 2017
    #4
  5. Beaver

    Beaver 2020 Rookie of the Year Admiral (Supporter)

    Joined:
    Apr 12, 2013
    Posts:
    3,676
    Location:
    Central PA
    A stern is born...
    Guess Hull 2.png

    Beaver, Mar 20, 2017
    #5
  6. pigeonfarmboy

    pigeonfarmboy Well-Known Member

    Joined:
    Apr 26, 2016
    Posts:
    245
    Location:
    Champaign, IL
    I need to learn how to draw more organic shapes like this.

    pigeonfarmboy, Mar 21, 2017
    #6
  7. ish311

    ish311 Active Member

    Joined:
    Aug 18, 2014
    Posts:
    527
    Location:
    North Central Florida
    create the spar sections and loft between them. the more spar formers the better the final shape wil look. (this is for pigeon)

    ish311, Mar 21, 2017
    #7
  8. Admiral Where Did He Go?

    Admiral Where Did He Go? Member

    Joined:
    Dec 27, 2016
    Posts:
    54
    Location:
    Petite Riviere, Nova Scotia
    a battleship of some sort......:) and I right? I need to see more to figure it out.

    Admiral Where Did He Go?, Mar 21, 2017
    #8
  9. Beaver

    Beaver 2020 Rookie of the Year Admiral (Supporter)

    Joined:
    Apr 12, 2013
    Posts:
    3,676
    Location:
    Central PA
    Nah, not a battleship. I'll try to get a more updated photo of the hull on here tonight.

    Beaver, Mar 21, 2017
    #9
  10. SteveT44

    SteveT44 Well-Known Member

    Joined:
    Nov 1, 2009
    Posts:
    1,856
    Location:
    MD
    Algerie?

    SteveT44, Mar 21, 2017
    #10
  11. Beaver

    Beaver 2020 Rookie of the Year Admiral (Supporter)

    Joined:
    Apr 12, 2013
    Posts:
    3,676
    Location:
    Central PA
    Nope!

    Beaver, Mar 21, 2017
    #11
  12. Beaver

    Beaver 2020 Rookie of the Year Admiral (Supporter)

    Joined:
    Apr 12, 2013
    Posts:
    3,676
    Location:
    Central PA
    Here is the hull as it sits now. Stern still needs a lot of work yet.
    Guess Hull 3.png

    Beaver, Mar 21, 2017
    #12
  13. Beaver

    Beaver 2020 Rookie of the Year Admiral (Supporter)

    Joined:
    Apr 12, 2013
    Posts:
    3,676
    Location:
    Central PA
    A while back I tried modeling an Algerie. Turns out I really didn't know what I was doing and this is what I got. :oops: As you can see, I've improved.
    FN Algerie.png

    Last edited: Mar 21, 2017
    Beaver, Mar 21, 2017
    #13
  14. SteveT44

    SteveT44 Well-Known Member

    Joined:
    Nov 1, 2009
    Posts:
    1,856
    Location:
    MD
    SteveT44, Mar 21, 2017
    #14
  15. Beaver

    Beaver 2020 Rookie of the Year Admiral (Supporter)

    Joined:
    Apr 12, 2013
    Posts:
    3,676
    Location:
    Central PA
    I've been using Autodesk Fusion 360. I've played around with Delftship in the past, but never really learned how to use it properly.
    My goal with this hull is to create a set of plans from it. I found a set of hull lines for this ship, but I have no clue as to the spacing of the ribs. So I've been using the builder's side and top profile to determine rib station position then lofting between them to check the hull shape. Once I'm happy with the hull shape I'll pull ribs out wherever I want them plus have a top and side profile.

    Beaver, Mar 21, 2017
    #15
  16. Beaver

    Beaver 2020 Rookie of the Year Admiral (Supporter)

    Joined:
    Apr 12, 2013
    Posts:
    3,676
    Location:
    Central PA
    Stern feature added. Should give you a better idea of what kind of ship it is.
    Guess Ship 4.png

    Last edited: Mar 23, 2017
    Beaver, Mar 23, 2017
    #16
  17. WillCover

    WillCover -->> C T D <<--

    Joined:
    Nov 1, 2009
    Posts:
    658
    Location:
    Harrison, Michigan
    CVB-41?

    WillCover, Mar 23, 2017
    #17
  18. Beaver

    Beaver 2020 Rookie of the Year Admiral (Supporter)

    Joined:
    Apr 12, 2013
    Posts:
    3,676
    Location:
    Central PA
    You're on the right track, Will, but that's not it. :)
    I expect somebody will have this before noon tomorrow...

    Beaver, Mar 23, 2017
    #18
  19. Xanthar

    Xanthar Well-Known Member

    Joined:
    Sep 13, 2015
    Posts:
    656
    Location:
    Upstate NY
    A Liberty Ship?

    Xanthar, Mar 23, 2017
    #19
  20. Beaver

    Beaver 2020 Rookie of the Year Admiral (Supporter)

    Joined:
    Apr 12, 2013
    Posts:
    3,676
    Location:
    Central PA
    Nope, good free plans for them everywhere.

    Beaver, Mar 23, 2017
    #20
